Usage Page (Monitor VESA VCP),
Usage (10h, Brightness),
Logical Minimum (400),
Logical Maximum (60000),
Unit (Centimeter^-2 * Candela),
Unit Exponent (14),
Report Size (32),
Report Count (1),
Feature (Variable, Null State),

struct backlight_device *
devm_backlight_device_register(struct device *dev, const char *name,
			       struct device *parent, void *devdata,
			       const struct backlight_ops *ops,
			       const struct backlight_properties *props);

bool (struct backlight_ops).(*controls_device)

bool (struct backlight_ops).(*controls_device)

/*
 * detect_link_and_local_sink() - Detect if a sink is attached to a given link
 *
 * link->local_sink is created or destroyed as needed.
 *
 * This does not create remote sinks.
 */
static bool detect_link_and_local_sink(struct dc_link *link,
				  enum dc_detect_reason reason)
{
	/* code omitted */

		/* From Disconnected-to-Connected. */
		switch (link->connector_signal) {
		case SIGNAL_TYPE_HDMI_TYPE_A: {
			sink_caps.transaction_type = DDC_TRANSACTION_TYPE_I2C;
			if (aud_support->hdmi_audio_native)
				sink_caps.signal = SIGNAL_TYPE_HDMI_TYPE_A;
			else
				sink_caps.signal = SIGNAL_TYPE_DVI_SINGLE_LINK;
			break;
		}

		case SIGNAL_TYPE_DVI_SINGLE_LINK: {
			sink_caps.transaction_type = DDC_TRANSACTION_TYPE_I2C;
			sink_caps.signal = SIGNAL_TYPE_DVI_SINGLE_LINK;
			break;
		}

		case SIGNAL_TYPE_DVI_DUAL_LINK: {
			sink_caps.transaction_type = DDC_TRANSACTION_TYPE_I2C;
			sink_caps.signal = SIGNAL_TYPE_DVI_DUAL_LINK;
			break;
		}

		case SIGNAL_TYPE_LVDS: {
			sink_caps.transaction_type = DDC_TRANSACTION_TYPE_I2C;
			sink_caps.signal = SIGNAL_TYPE_LVDS;
			break;
		}

		case SIGNAL_TYPE_EDP: {
			detect_edp_sink_caps(link);
			read_current_link_settings_on_detect(link);

			/* Disable power sequence on MIPI panel + converter
			 */
			if (dc->config.enable_mipi_converter_optimization &&
				dc_ctx->dce_version == DCN_VERSION_3_01 &&
				link->dpcd_caps.sink_dev_id == DP_BRANCH_DEVICE_ID_0022B9 &&
				memcmp(&link->dpcd_caps.branch_dev_name, DP_SINK_BRANCH_DEV_NAME_7580,
					sizeof(link->dpcd_caps.branch_dev_name)) == 0) {
				dc->config.edp_no_power_sequencing = true;

				if (!link->dpcd_caps.set_power_state_capable_edp)
					link->wa_flags.dp_keep_receiver_powered = true;
			}

			sink_caps.transaction_type = DDC_TRANSACTION_TYPE_I2C_OVER_AUX;
			sink_caps.signal = SIGNAL_TYPE_EDP;
			break;
		}

		case SIGNAL_TYPE_DISPLAY_PORT: {

			/* wa HPD high coming too early*/
			if (link->ep_type == DISPLAY_ENDPOINT_PHY &&
			    link->link_enc->features.flags.bits.DP_IS_USB_C == 1) {

				/* if alt mode times out, return false */
				if (!wait_for_entering_dp_alt_mode(link))
					return false;
			}

			if (!detect_dp(link, &sink_caps, reason)) {

				if (prev_sink)
					dc_sink_release(prev_sink);
				return false;
			}

			/* Active SST downstream branch device unplug*/
			if (link->type == dc_connection_sst_branch &&
			    link->dpcd_caps.sink_count.bits.SINK_COUNT == 0) {
				if (prev_sink)
					/* Downstream unplug */
					dc_sink_release(prev_sink);
				return true;
			}

			/* disable audio for non DP to HDMI active sst converter */
			if (link->type == dc_connection_sst_branch &&
					is_dp_active_dongle(link) &&
					(link->dpcd_caps.dongle_type !=
							DISPLAY_DONGLE_DP_HDMI_CONVERTER))
				converter_disable_audio = true;

			/* limited link rate to HBR3 for DPIA until we implement USB4 V2 */
			if (link->ep_type == DISPLAY_ENDPOINT_USB4_DPIA &&
					link->reported_link_cap.link_rate > LINK_RATE_HIGH3)
				link->reported_link_cap.link_rate = LINK_RATE_HIGH3;

			if (link->dpcd_caps.usb4_dp_tun_info.dp_tun_cap.bits.dp_tunneling
					&& link->dpcd_caps.usb4_dp_tun_info.dp_tun_cap.bits.dpia_bw_alloc
					&& link->dpcd_caps.usb4_dp_tun_info.driver_bw_cap.bits.driver_bw_alloc_support) {
				if (link_dpia_enable_usb4_dp_bw_alloc_mode(link) == false)
					link->dpcd_caps.usb4_dp_tun_info.dp_tun_cap.bits.dpia_bw_alloc = false;
			}
			break;
		}

		default:
			DC_ERROR("Invalid connector type! signal:%d\n",
				 link->connector_signal);
			if (prev_sink)
				dc_sink_release(prev_sink);
			return false;
		} /* switch() */

		/* code omitted */

		set_ddc_transaction_type(link->ddc,
						     sink_caps.transaction_type);

 	/* code omitted */
}

static bool detect_dp(struct dc_link *link,
		      struct display_sink_capability *sink_caps,
		      enum dc_detect_reason reason)
{
	struct audio_support *audio_support = &link->dc->res_pool->audio_support;

	sink_caps->signal = link_detect_sink_signal_type(link, reason);
	sink_caps->transaction_type =
		get_ddc_transaction_type(sink_caps->signal);

	if (sink_caps->transaction_type == DDC_TRANSACTION_TYPE_I2C_OVER_AUX) {
		sink_caps->signal = SIGNAL_TYPE_DISPLAY_PORT;
		if (!detect_dp_sink_caps(link)) {
			return false;
		}

		if (is_dp_branch_device(link))
			/* DP SST branch */
			link->type = dc_connection_sst_branch;
	} else {
		if (link->dc->debug.disable_dp_plus_plus_wa &&
				link->link_enc->features.flags.bits.IS_UHBR20_CAPABLE)
			return false;

		/* DP passive dongles */
		sink_caps->signal = dp_passive_dongle_detection(link->ddc,
								sink_caps,
								audio_support);
		link->dpcd_caps.dongle_type = sink_caps->dongle_type;
		link->dpcd_caps.is_dongle_type_one = sink_caps->is_dongle_type_one;
		link->dpcd_caps.dpcd_rev.raw = 0;
		link->dpcd_caps.usb4_dp_tun_info.dp_tun_cap.raw = 0;
	}

	return true;
}

static struct amdgpu_i2c_adapter *
create_i2c(struct ddc_service *ddc_service, bool oem)
{
	struct amdgpu_device *adev = ddc_service->ctx->driver_context;
	struct amdgpu_i2c_adapter *i2c;

	i2c = kzalloc(sizeof(struct amdgpu_i2c_adapter), GFP_KERNEL);
	if (!i2c)
		return NULL;
	i2c->base.owner = THIS_MODULE;
	i2c->base.dev.parent = &adev->pdev->dev;
	i2c->base.algo = &amdgpu_dm_i2c_algo;
	if (oem)
		snprintf(i2c->base.name, sizeof(i2c->base.name), "AMDGPU DM i2c OEM bus");
	else
		snprintf(i2c->base.name, sizeof(i2c->base.name), "AMDGPU DM i2c hw bus %d",
			 ddc_service->link->link_index);
	i2c_set_adapdata(&i2c->base, i2c);
	i2c->ddc_service = ddc_service;
	i2c->oem = oem;

	return i2c;
}

/*
 * Note: this function assumes that dc_link_detect() was called for the
 * dc_link which will be represented by this aconnector.
 */
static int amdgpu_dm_connector_init(struct amdgpu_display_manager *dm,
				    struct amdgpu_dm_connector *aconnector,
				    u32 link_index,
				    struct amdgpu_encoder *aencoder)
{
	int res = 0;
	int connector_type;
	struct dc *dc = dm->dc;
	struct dc_link *link = dc_get_link_at_index(dc, link_index);
	struct amdgpu_i2c_adapter *i2c;

	/* Not needed for writeback connector */
	link->priv = aconnector;


	i2c = create_i2c(link->ddc, false);
	if (!i2c) {
		drm_err(adev_to_drm(dm->adev), "Failed to create i2c adapter data\n");
		return -ENOMEM;
	}

	aconnector->i2c = i2c;
	res = i2c_add_adapter(&i2c->base);

	if (res) {
		drm_err(adev_to_drm(dm->adev), "Failed to register hw i2c %d\n", link->link_index);
		goto out_free;
	}

	connector_type = to_drm_connector_type(link->connector_signal);

	res = drm_connector_init_with_ddc(
			dm->ddev,
			&aconnector->base,
			&amdgpu_dm_connector_funcs,
			connector_type,
			&i2c->base);

	/* code omitted */

sudo strace -e openat ddcutil probe |& grep /dev/i2c
openat(AT_FDCWD, "/dev/i2c-5", O_RDWR)  = 3
openat(AT_FDCWD, "/dev/i2c-6", O_RDWR)  = 3
openat(AT_FDCWD, "/dev/i2c-7", O_RDWR)  = 3
openat(AT_FDCWD, "/dev/i2c-8", O_RDWR)  = 3
openat(AT_FDCWD, "/dev/i2c-9", O_RDWR)  = 3
openat(AT_FDCWD, "/dev/i2c-10", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-11", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-12", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-13", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-14", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-15", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-16", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-17", O_RDWR) = 3
openat(AT_FDCWD, "/dev/i2c-14", O_RDWR) = 3

// SPDX-License-Identifier: GPL-2.0

// Copyright (C) 2025 Rahul Rameshbabu <sergeantsagara@protonmail.com>

//! Rust reference HID driver for Glorious Model O and O- mice.

use kernel::{self, bindings, device, hid, prelude::*};

struct GloriousRust;

kernel::hid_device_table!(
    HID_TABLE,
    MODULE_HID_TABLE,
    <GloriousRust as hid::Driver>::IdInfo,
    [(
        hid::DeviceId::new_usb(
            hid::Group::Generic,
            bindings::USB_VENDOR_ID_SINOWEALTH,
            bindings::USB_DEVICE_ID_GLORIOUS_MODEL_O,
        ),
        (),
    )]
);

#[vtable]
impl hid::Driver for GloriousRust {
    type IdInfo = ();
    const ID_TABLE: hid::IdTable<Self::IdInfo> = &HID_TABLE;

    /// Fix the Glorious Model O and O- consumer input report descriptor to use
    /// the variable and relative flag, while clearing the const flag.
    ///
    /// Without this fixup, inputs from the mice will be ignored.
    fn report_fixup<'a, 'b: 'a>(hdev: &hid::Device<device::Core>, rdesc: &'b mut [u8]) -> &'a [u8] {
        if rdesc.len() == 213
            && (rdesc[84] == 129 && rdesc[85] == 3)
            && (rdesc[112] == 129 && rdesc[113] == 3)
            && (rdesc[140] == 129 && rdesc[141] == 3)
        {
            dev_info!(
                hdev.as_ref(),
                "patching Glorious Model O consumer control report descriptor\n"
            );

            rdesc[85] = hid::MAIN_ITEM_VARIABLE | hid::MAIN_ITEM_RELATIVE;
            rdesc[113] = hid::MAIN_ITEM_VARIABLE | hid::MAIN_ITEM_RELATIVE;
            rdesc[141] = hid::MAIN_ITEM_VARIABLE | hid::MAIN_ITEM_RELATIVE;
        }

        rdesc
    }
}

kernel::module_hid_driver! {
    type: GloriousRust,
    name: "GloriousRust",
    authors: ["Rahul Rameshbabu <sergeantsagara@protonmail.com>"],
    description: "Rust reference HID driver for Glorious Model O and O- mice",
    license: "GPL",
}

// SPDX-License-Identifier: GPL-2.0

// Copyright (C) 2025 Rahul Rameshbabu <sergeantsagara@protonmail.com>

//! Abstractions for the HID interface.
//!
//! C header: [`include/linux/hid.h`](srctree/include/linux/hid.h)

use crate::{device, device_id::RawDeviceId, driver, error::*, prelude::*, types::Opaque};
use core::{
    marker::PhantomData,
    ptr::{addr_of_mut, NonNull},
};

/// Indicates the item is static read-only.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_CONSTANT: u8 = bindings::HID_MAIN_ITEM_CONSTANT as u8;

/// Indicates the item represents data from a physical control.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_VARIABLE: u8 = bindings::HID_MAIN_ITEM_VARIABLE as u8;

/// Indicates the item should be treated as a relative change from the previous
/// report.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_RELATIVE: u8 = bindings::HID_MAIN_ITEM_RELATIVE as u8;

/// Indicates the item should wrap around when reaching the extreme high or
/// extreme low values.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_WRAP: u8 = bindings::HID_MAIN_ITEM_WRAP as u8;

/// Indicates the item should wrap around when reaching the extreme high or
/// extreme low values.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_NONLINEAR: u8 = bindings::HID_MAIN_ITEM_NONLINEAR as u8;

/// Indicates whether the control has a preferred state it will physically
/// return to without user intervention.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_NO_PREFERRED: u8 = bindings::HID_MAIN_ITEM_NO_PREFERRED as u8;

/// Indicates whether the control has a physical state where it will not send
/// any reports.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_NULL_STATE: u8 = bindings::HID_MAIN_ITEM_NULL_STATE as u8;

/// Indicates whether the control requires host system logic to change state.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_VOLATILE: u8 = bindings::HID_MAIN_ITEM_VOLATILE as u8;

/// Indicates whether the item is fixed size or a variable buffer of bytes.
///
/// Refer to [Device Class Definition for HID 1.11]
/// Section 6.2.2.5 Input, Output, and Feature Items.
///
/// [Device Class Definition for HID 1.11]: https://www.usb.org/sites/default/files/hid1_11.pdf
pub const MAIN_ITEM_BUFFERED_BYTE: u8 = bindings::HID_MAIN_ITEM_BUFFERED_BYTE as u8;

/// HID device groups are intended to help categories HID devices based on a set
/// of common quirks and logic that they will require to function correctly.
#[repr(u16)]
pub enum Group {
    /// Used to match a device against any group when probing.
    Any = bindings::HID_GROUP_ANY as u16,

    /// Indicates a generic device that should need no custom logic from the
    /// core HID stack.
    Generic = bindings::HID_GROUP_GENERIC as u16,

    /// Maps multitouch devices to hid-multitouch instead of hid-generic.
    Multitouch = bindings::HID_GROUP_MULTITOUCH as u16,

    /// Used for autodetecing and mapping of HID sensor hubs to
    /// hid-sensor-hub.
    SensorHub = bindings::HID_GROUP_SENSOR_HUB as u16,

    /// Used for autodetecing and mapping Win 8 multitouch devices to set the
    /// needed quirks.
    MultitouchWin8 = bindings::HID_GROUP_MULTITOUCH_WIN_8 as u16,

    // Vendor-specific device groups.
    /// Used to distinguish Synpatics touchscreens from other products. The
    /// touchscreens will be handled by hid-multitouch instead, while everything
    /// else will be managed by hid-rmi.
    RMI = bindings::HID_GROUP_RMI as u16,

    /// Used for hid-core handling to automatically identify Wacom devices and
    /// have them probed by hid-wacom.
    Wacom = bindings::HID_GROUP_WACOM as u16,

    /// Used by logitech-djreceiver and logitech-djdevice to autodetect if
    /// devices paied to the DJ receivers are DJ devices and handle them with
    /// the device driver.
    LogitechDJDevice = bindings::HID_GROUP_LOGITECH_DJ_DEVICE as u16,

    /// Since the Valve Steam Controller only has vendor-specific usages,
    /// prevent hid-generic from parsing its reports since there would be
    /// nothing hid-generic could do for the device.
    Steam = bindings::HID_GROUP_STEAM as u16,

    /// Used to differentiate 27 Mhz frequency Logitech DJ devices from other
    /// Logitech DJ devices.
    Logitech27MHzDevice = bindings::HID_GROUP_LOGITECH_27MHZ_DEVICE as u16,

    /// Used for autodetecting and mapping Vivaldi devices to hid-vivaldi.
    Vivaldi = bindings::HID_GROUP_VIVALDI as u16,
}

// TODO: use `const_trait_impl` once stabilized:
//
// ```
// impl const From<Group> for u16 {
//     /// [`Group`] variants are represented by [`u16`] values.
//     fn from(value: Group) -> Self {
//         value as Self
//     }
// }
// ```
impl Group {
    /// Internal function used to convert [`Group`] variants into [`u16`].
    const fn into(self) -> u16 {
        self as u16
    }
}

impl From<u16> for Group {
    /// [`u16`] values can be safely converted to [`Group`] variants.
    fn from(value: u16) -> Self {
        match value.into() {
            bindings::HID_GROUP_GENERIC => Group::Generic,
            bindings::HID_GROUP_MULTITOUCH => Group::Multitouch,
            bindings::HID_GROUP_SENSOR_HUB => Group::SensorHub,
            bindings::HID_GROUP_MULTITOUCH_WIN_8 => Group::MultitouchWin8,
            bindings::HID_GROUP_RMI => Group::RMI,
            bindings::HID_GROUP_WACOM => Group::Wacom,
            bindings::HID_GROUP_LOGITECH_DJ_DEVICE => Group::LogitechDJDevice,
            bindings::HID_GROUP_STEAM => Group::Steam,
            bindings::HID_GROUP_LOGITECH_27MHZ_DEVICE => Group::Logitech27MHzDevice,
            bindings::HID_GROUP_VIVALDI => Group::Vivaldi,
            _ => Group::Any,
        }
    }
}

/// The HID device representation.
///
/// This structure represents the Rust abstraction for a C `struct hid_device`.
/// The implementation abstracts the usage of an already existing C `struct
/// hid_device` within Rust code that we get passed from the C side.
///
/// # Invariants
///
/// A [`Device`] instance represents a valid `struct hid_device` created by the
/// C portion of the kernel.
#[repr(transparent)]
pub struct Device<Ctx: device::DeviceContext = device::Normal>(
    Opaque<bindings::hid_device>,
    PhantomData<Ctx>,
);

impl<Ctx: device::DeviceContext> Device<Ctx> {
    fn as_raw(&self) -> *mut bindings::hid_device {
        self.0.get()
    }

    /// Returns the HID transport bus ID.
    pub fn bus(&self) -> u16 {
        // SAFETY: `self.as_raw` is a valid pointer to a `struct hid_device`
        unsafe { *self.as_raw() }.bus
    }

    /// Returns the HID report group.
    pub fn group(&self) -> Group {
        // SAFETY: `self.as_raw` is a valid pointer to a `struct hid_device`
        unsafe { *self.as_raw() }.group.into()
    }

    /// Returns the HID vendor ID.
    pub fn vendor(&self) -> u32 {
        // SAFETY: `self.as_raw` is a valid pointer to a `struct hid_device`
        unsafe { *self.as_raw() }.vendor
    }

    /// Returns the HID product ID.
    pub fn product(&self) -> u32 {
        // SAFETY: `self.as_raw` is a valid pointer to a `struct hid_device`
        unsafe { *self.as_raw() }.product
    }
}

// SAFETY: `Device` is a transparent wrapper of a type that doesn't depend on `Device`'s generic
// argument.
kernel::impl_device_context_deref!(unsafe { Device });
kernel::impl_device_context_into_aref!(Device);

// SAFETY: Instances of `Device` are always reference-counted.
unsafe impl crate::types::AlwaysRefCounted for Device {
    fn inc_ref(&self) {
        // SAFETY: The existence of a shared reference guarantees that the refcount is non-zero.
        unsafe { bindings::get_device(&raw mut (*self.as_raw()).dev) };
    }

    unsafe fn dec_ref(obj: NonNull<Self>) {
        // SAFETY: The safety requirements guarantee that the refcount is non-zero.
        unsafe { bindings::put_device(&raw mut (*obj.cast::<bindings::hid_device>().as_ptr()).dev) }
    }
}

impl<Ctx: device::DeviceContext> AsRef<device::Device<Ctx>> for Device<Ctx> {
    fn as_ref(&self) -> &device::Device<Ctx> {
        // SAFETY: By the type invariant of `Self`, `self.as_raw()` is a pointer to a valid
        // `struct hid_device`.
        let dev = unsafe { addr_of_mut!((*self.as_raw()).dev) };

        // SAFETY: `dev` points to a valid `struct device`.
        unsafe { device::Device::as_ref(dev) }
    }
}

/// Abstraction for the HID device ID structure `struct hid_device_id`.
#[repr(transparent)]
#[derive(Clone, Copy)]
pub struct DeviceId(bindings::hid_device_id);

impl DeviceId {
    /// Equivalent to C's `HID_USB_DEVICE` macro.
    ///
    /// Create a new `hid::DeviceId` from a group, vendor ID, and device ID
    /// number.
    pub const fn new_usb(group: Group, vendor: u32, product: u32) -> Self {
        Self(bindings::hid_device_id {
            bus: 0x3, // BUS_USB
            group: group.into(),
            vendor,
            product,
            driver_data: 0,
        })
    }

    /// Returns the HID transport bus ID.
    pub fn bus(&self) -> u16 {
        self.0.bus
    }

    /// Returns the HID report group.
    pub fn group(&self) -> Group {
        self.0.group.into()
    }

    /// Returns the HID vendor ID.
    pub fn vendor(&self) -> u32 {
        self.0.vendor
    }

    /// Returns the HID product ID.
    pub fn product(&self) -> u32 {
        self.0.product
    }
}

// SAFETY:
// * `DeviceId` is a `#[repr(transparent)` wrapper of `hid_device_id` and does not add
//   additional invariants, so it's safe to transmute to `RawType`.
// * `DRIVER_DATA_OFFSET` is the offset to the `driver_data` field.
unsafe impl RawDeviceId for DeviceId {
    type RawType = bindings::hid_device_id;

    const DRIVER_DATA_OFFSET: usize = core::mem::offset_of!(bindings::hid_device_id, driver_data);

    fn index(&self) -> usize {
        self.0.driver_data
    }
}

/// [`IdTable`] type for HID.
pub type IdTable<T> = &'static dyn kernel::device_id::IdTable<DeviceId, T>;

/// Create a HID [`IdTable`] with its alias for modpost.
#[macro_export]
macro_rules! hid_device_table {
    ($table_name:ident, $module_table_name:ident, $id_info_type: ty, $table_data: expr) => {
        const $table_name: $crate::device_id::IdArray<
            $crate::hid::DeviceId,
            $id_info_type,
            { $table_data.len() },
        > = $crate::device_id::IdArray::new($table_data);

        $crate::module_device_table!("hid", $module_table_name, $table_name);
    };
}

/// The HID driver trait.
///
/// # Examples
///
/// ```
/// use kernel::{bindings, device, hid};
///
/// struct MyDriver;
///
/// kernel::hid_device_table!(
///     HID_TABLE,
///     MODULE_HID_TABLE,
///     <MyDriver as hid::Driver>::IdInfo,
///     [(
///         hid::DeviceId::new_usb(
///             hid::Group::Steam,
///             bindings::USB_VENDOR_ID_VALVE,
///             bindings::USB_DEVICE_ID_STEAM_DECK,
///         ),
///         (),
///     )]
/// );
///
/// #[vtable]
/// impl hid::Driver for MyDriver {
///     type IdInfo = ();
///     const ID_TABLE: hid::IdTable<Self::IdInfo> = &HID_TABLE;
///
///     /// This function is optional to implement.
///     fn report_fixup<'a, 'b: 'a>(_hdev: &hid::Device<device::Core>, rdesc: &'b mut [u8]) -> &'a [u8] {
///         // Perform some report descriptor fixup.
///         rdesc
///     }
/// }
/// ```
/// Drivers must implement this trait in order to get a HID driver registered.
/// Please refer to the `Adapter` documentation for an example.
#[vtable]
pub trait Driver: Send {
    /// The type holding information about each device id supported by the driver.
    // TODO: Use `associated_type_defaults` once stabilized:
    //
    // ```
    // type IdInfo: 'static = ();
    // ```
    type IdInfo: 'static;

    /// The table of device ids supported by the driver.
    const ID_TABLE: IdTable<Self::IdInfo>;

    /// Called before report descriptor parsing. Can be used to mutate the
    /// report descriptor before the core HID logic processes the descriptor.
    /// Useful for problematic report descriptors that prevent HID devices from
    /// functioning correctly.
    ///
    /// Optional to implement.
    fn report_fixup<'a, 'b: 'a>(_hdev: &Device<device::Core>, _rdesc: &'b mut [u8]) -> &'a [u8] {
        build_error!(VTABLE_DEFAULT_ERROR)
    }
}

/// An adapter for the registration of HID drivers.
pub struct Adapter<T: Driver>(T);

// SAFETY: A call to `unregister` for a given instance of `RegType` is guaranteed to be valid if
// a preceding call to `register` has been successful.
unsafe impl<T: Driver + 'static> driver::RegistrationOps for Adapter<T> {
    type RegType = bindings::hid_driver;

    unsafe fn register(
        hdrv: &Opaque<Self::RegType>,
        name: &'static CStr,
        module: &'static ThisModule,
    ) -> Result {
        // SAFETY: It's safe to set the fields of `struct hid_driver` on initialization.
        unsafe {
            (*hdrv.get()).name = name.as_char_ptr();
            (*hdrv.get()).id_table = T::ID_TABLE.as_ptr();
            (*hdrv.get()).report_fixup = if T::HAS_REPORT_FIXUP {
                Some(Self::report_fixup_callback)
            } else {
                None
            };
        }

        // SAFETY: `hdrv` is guaranteed to be a valid `RegType`
        to_result(unsafe {
            bindings::__hid_register_driver(hdrv.get(), module.0, name.as_char_ptr())
        })
    }

    unsafe fn unregister(hdrv: &Opaque<Self::RegType>) {
        // SAFETY: `hdrv` is guaranteed to be a valid `RegType`
        unsafe { bindings::hid_unregister_driver(hdrv.get()) }
    }
}

impl<T: Driver + 'static> Adapter<T> {
    extern "C" fn report_fixup_callback(
        hdev: *mut bindings::hid_device,
        buf: *mut u8,
        size: *mut kernel::ffi::c_uint,
    ) -> *const u8 {
        // SAFETY: The HID subsystem only ever calls the report_fixup callback
        // with a valid pointer to a `struct hid_device`.
        //
        // INVARIANT: `hdev` is valid for the duration of
        // `report_fixup_callback()`.
        let hdev = unsafe { &*hdev.cast::<Device<device::Core>>() };

        // SAFETY: The HID subsystem only ever calls the report_fixup callback
        // with a valid pointer to a `kernel::ffi::c_uint`.
        //
        // INVARIANT: `size` is valid for the duration of
        // `report_fixup_callback()`.
        let buf_len: usize = match unsafe { *size }.try_into() {
            Ok(len) => len,
            Err(e) => {
                dev_err!(
                    hdev.as_ref(),
                    "Cannot fix report description due to {}!\n",
                    e
                );

                return buf;
            }
        };

        // Build a mutable Rust slice from `buf` and `size`.
        //
        // SAFETY: The HID subsystem only ever calls the `report_fixup callback`
        // with a valid pointer to a `u8` buffer.
        //
        // INVARIANT: `buf` is valid for the duration of
        // `report_fixup_callback()`.
        let rdesc_slice = unsafe { core::slice::from_raw_parts_mut(buf, buf_len) };
        let rdesc_slice = T::report_fixup(hdev, rdesc_slice);

        match rdesc_slice.len().try_into() {
            // SAFETY: The HID subsystem only ever calls the report_fixup
            // callback with a valid pointer to a `kernel::ffi::c_uint`.
            //
            // INVARIANT: `size` is valid for the duration of
            // `report_fixup_callback()`.
            Ok(len) => unsafe { *size = len },
            Err(e) => {
                dev_err!(
                    hdev.as_ref(),
                    "Fixed report description will not be used due to {}!\n",
                    e
                );

                return buf;
            }
        }

        rdesc_slice.as_ptr()
    }
}

/// Declares a kernel module that exposes a single HID driver.
///
/// # Examples
///
/// ```ignore
/// kernel::module_hid_driver! {
///     type: MyDriver,
///     name: "Module name",
///     authors: ["Author name"],
///     description: "Description",
///     license: "GPL",
/// }
/// ```
#[macro_export]
macro_rules! module_hid_driver {
    ($($f:tt)*) => {
        $crate::module_driver!(<T>, $crate::hid::Adapter<T>, { $($f)* });
    };
}

/// A DRM connector representation that extends `struct drm_connector`.
///
/// This connector implementation enables DRM connector API development in Rust
/// and exposing said functionality to both C and Rust DRM consumers.
#[pin_data]
pub struct Connector {
    #[pin]
    raw_connector: Opaque<*mut bindings::drm_connector>,
    rust_only_attribute: bool,

    /// A connector needs to be pinned since it is referred to using a raw
    /// pointer field `rust` in the C DRM `struct drm_connector` implementation.
    #[pin]
    _pin: PhantomPinned,
}

/// C entry point for initializing the Rust extension for a DRM connector.
///
/// When a DRM connector is being initialized in the core C stack, the Rust
/// `Connector` extension needs to be allocated and initialized.
#[export]
pub unsafe extern "C" fn drm_connector_init_rust(
    raw_connector: *mut bindings::drm_connector,
) -> kernel::ffi::c_int {
    let connector = match KBox::pin_init(
        try_pin_init!(Connector{
            raw_connector <- Opaque::new(raw_connector),
            rust_only_attribute: true,
            _pin: PhantomPinned,
        }),
        GFP_KERNEL,
    ) {
        Ok(kbox) => kbox,
        Err(_) => return -ENOMEM.to_errno(),
    };

    // Provide the C `struct drm_connector` instance a handle to the Rust
    // `drm::connector:Connector` implementation for Rust connector APIs and the
    // `drm_connector_cleanup_rust` cleanup call.
    //
    // SAFETY: `raw_connector` is a valid pointer with a `rust` field that does
    // not already point to an initialized `drm::connector::Connector`
    unsafe { (*raw_connector).rust = connector.into_foreign() };

    0
}

/// C entry point for tearing down the Rust extension for a DRM connector.
///
/// When a DRM connector is being cleaned up from the core C stack, the Rust
/// `Connector` extension instance needs to be dropped.
#[export]
pub unsafe extern "C" fn drm_connector_cleanup_rust(raw_connector: *mut bindings::drm_connector) {
    // SAFETY: By the safety requirements of this function, the `rust` field of
    // `raw_connector`, a valid pointer, is initialized by the `into_foreign()`
    // call made by `drm_connector_init_rust()`.
    drop(unsafe { <Pin<KBox<Connector>>>::from_foreign((*raw_connector).rust) });
}

#if IS_ENABLED(CONFIG_RUST)
int drm_connector_init_rust(struct drm_connector *connector);
void drm_connector_cleanup_rust(struct drm_connector *connector);
#else
static inline int drm_connector_init_rust(struct drm_connector *connector)
{
	return 0;
}

static inline void drm_connector_cleanup_rust(struct drm_connector *connector)
{
}
#endif

static int drm_connector_init_only(struct drm_device *dev,
				   struct drm_connector *connector,
				   const struct drm_connector_funcs *funcs,
				   int connector_type,
				   struct i2c_adapter *ddc)
{
	struct drm_mode_config *config = &dev->mode_config;
	int ret;
	struct ida *connector_ida =
		&drm_connector_enum_list[connector_type].ida;

	WARN_ON(drm_drv_uses_atomic_modeset(dev) &&
		(!funcs->atomic_destroy_state ||
		 !funcs->atomic_duplicate_state));

	ret = __drm_mode_object_add(dev, &connector->base,
				    DRM_MODE_OBJECT_CONNECTOR,
				    false, drm_connector_free);
	if (ret)
		return ret;

	connector->base.properties = &connector->properties;
	connector->dev = dev;
	connector->funcs = funcs;

	/* connector index is used with 32bit bitmasks */
	ret = ida_alloc_max(&config->connector_ida, 31, GFP_KERNEL);
	if (ret < 0) {
		DRM_DEBUG_KMS("Failed to allocate %s connector index: %d\n",
			      drm_connector_enum_list[connector_type].name,
			      ret);
		goto out_put;
	}
	connector->index = ret;
	ret = 0;

	connector->connector_type = connector_type;
	connector->connector_type_id =
		ida_alloc_min(connector_ida, 1, GFP_KERNEL);
	if (connector->connector_type_id < 0) {
		ret = connector->connector_type_id;
		goto out_put_id;
	}
	connector->name =
		kasprintf(GFP_KERNEL, "%s-%d",
			  drm_connector_enum_list[connector_type].name,
			  connector->connector_type_id);
	if (!connector->name) {
		ret = -ENOMEM;
		goto out_put_type_id;
	}

	ret = drm_connector_init_rust(connector);
	if (ret)
		goto out_put_name;

	/* provide ddc symlink in sysfs */
	connector->ddc = ddc;

	INIT_LIST_HEAD(&connector->head);
	INIT_LIST_HEAD(&connector->global_connector_list_entry);
	INIT_LIST_HEAD(&connector->probed_modes);
	INIT_LIST_HEAD(&connector->modes);
	mutex_init(&connector->mutex);
	mutex_init(&connector->cec.mutex);
	mutex_init(&connector->eld_mutex);
	mutex_init(&connector->edid_override_mutex);
	mutex_init(&connector->hdmi.infoframes.lock);
	mutex_init(&connector->hdmi_audio.lock);
	connector->edid_blob_ptr = NULL;
	connector->epoch_counter = 0;
	connector->tile_blob_ptr = NULL;
	connector->status = connector_status_unknown;
	connector->display_info.panel_orientation =
		DRM_MODE_PANEL_ORIENTATION_UNKNOWN;

	drm_connector_get_cmdline_mode(connector);

	if (connector_type != DRM_MODE_CONNECTOR_VIRTUAL &&
	    connector_type != DRM_MODE_CONNECTOR_WRITEBACK)
		drm_connector_attach_edid_property(connector);

	drm_object_attach_property(&connector->base,
				      config->dpms_property, 0);

	drm_object_attach_property(&connector->base,
				   config->link_status_property,
				   0);

	drm_object_attach_property(&connector->base,
				   config->non_desktop_property,
				   0);
	drm_object_attach_property(&connector->base,
				   config->tile_property,
				   0);

	if (drm_core_check_feature(dev, DRIVER_ATOMIC)) {
		drm_object_attach_property(&connector->base, config->prop_crtc_id, 0);
	}

	connector->debugfs_entry = NULL;
out_put_name:
	if (ret)
		kfree(connector->name);
out_put_type_id:
	if (ret)
		ida_free(connector_ida, connector->connector_type_id);
out_put_id:
	if (ret)
		ida_free(&config->connector_ida, connector->index);
out_put:
	if (ret)
		drm_mode_object_unregister(dev, &connector->base);

	return ret;
}

void drm_connector_cleanup(struct drm_connector *connector)
{
	struct drm_device *dev = connector->dev;
	struct drm_display_mode *mode, *t;

	/* The connector should have been removed from userspace long before
	 * it is finally destroyed.
	 */
	if (WARN_ON(connector->registration_state ==
		    DRM_CONNECTOR_REGISTERED))
		drm_connector_unregister(connector);

	drm_connector_cleanup_rust(connector);

	platform_device_unregister(connector->hdmi_audio.codec_pdev);

	if (connector->privacy_screen) {
		drm_privacy_screen_put(connector->privacy_screen);
		connector->privacy_screen = NULL;
	}

	if (connector->tile_group) {
		drm_mode_put_tile_group(dev, connector->tile_group);
		connector->tile_group = NULL;
	}

	list_for_each_entry_safe(mode, t, &connector->probed_modes, head)
		drm_mode_remove(connector, mode);

	list_for_each_entry_safe(mode, t, &connector->modes, head)
		drm_mode_remove(connector, mode);

	ida_free(&drm_connector_enum_list[connector->connector_type].ida,
			  connector->connector_type_id);

	ida_free(&dev->mode_config.connector_ida, connector->index);

	kfree(connector->display_info.bus_formats);
	kfree(connector->display_info.vics);
	drm_mode_object_unregister(dev, &connector->base);
	kfree(connector->name);
	connector->name = NULL;
	fwnode_handle_put(connector->fwnode);
	connector->fwnode = NULL;

	drm_connector_remove(connector);

	WARN_ON(connector->state && !connector->funcs->atomic_destroy_state);
	if (connector->state && connector->funcs->atomic_destroy_state)
		connector->funcs->atomic_destroy_state(connector,
						       connector->state);

	mutex_destroy(&connector->hdmi_audio.lock);
	mutex_destroy(&connector->hdmi.infoframes.lock);
	mutex_destroy(&connector->mutex);

	memset(connector, 0, sizeof(*connector));

	if (dev->registered)
		drm_sysfs_hotplug_event(dev);
}
EXPORT_SYMBOL(drm_connector_cleanup);
